The ATEN CL1308 is a professional 1U rack-mount LCD KVM switch designed for server rooms, enterprise IT environments, and data centers where rack space is limited. It combines a 19-inch LED-backlit LCD monitor, full keyboard, touchpad, and an 8-port KVM switch into a compact single-rail sliding console.
Supporting both USB and PS/2 interfaces, the CL1308 allows administrators to manage up to 8 directly connected servers, with expansion to 128 computers via cascading, all from a single keyboard, monitor, and mouse. Multiple switching methods—including front-panel push buttons, hotkeys, and an intuitive multilingual OSD—make server administration fast and efficient. The integrated LED keyboard light ensures comfortable operation even in low-light server rooms.
Key Features
- 19-inch LED-backlit LCD console
- Integrated keyboard and touchpad
- Controls up to 8 computers directly
- Expandable to 128 servers through cascade
- Supports both USB and PS/2 computers
- Single-rail 1U rack-mount design
- Front panel push buttons, Hotkeys & OSD switching
- High-resolution VGA support up to 1920 × 1200 @ 60Hz (input)
- LCD resolution 1280 × 1024 @ 75Hz
- Exclusive LED keyboard illumination light
- Auto Scan monitoring
- Broadcast Mode
- Two-level password security
- Hot-pluggable design
- Firmware upgradeable
- No software installation required
- Supports Windows, Linux, macOS and Sun systems
Technical Specifications
| Specification | Details |
|---|---|
| Brand | ATEN |
| Model | CL1308 |
| Product Type | LCD KVM Switch |
| Direct Connections | 8 Computers |
| Maximum Connections | 128 (Cascade) |
| LCD Display | 19-inch TFT LED Backlit |
| LCD Resolution | 1280 × 1024 @ 75Hz |
| Maximum Video Input | 1920 × 1200 @ 60Hz |
| Video Interface | VGA |
| Keyboard/Mouse | USB & PS/2 |
| Switching Methods | OSD, Hotkeys, Push Buttons |
| KVM Ports | 8 × SPHD |
| Firmware Upgrade | RJ-11 |
| Power Input | IEC C14 |
| Rack Size | 1U |
| Mount Type | Single Rail Rack Mount |
| Operating Temperature | 0°C to 50°C |
| Input Power | 100–240V AC, 50/60Hz |
| Weight | Approx. 12.6 kg |
Applications
- Enterprise Server Rooms
- Data Centers
- Government Networks
- Financial Institutions
- Educational Campuses
- Manufacturing Plants
- Telecom Infrastructure
- Network Operation Centers (NOC)
- CCTV Control Rooms
- Industrial Automation
Benefits
- Saves valuable rack space with integrated LCD console
- Manage multiple servers from one workstation
- Reduce cabling complexity
- Increase maintenance efficiency
- Secure administrator access
- Supports mixed USB and PS/2 environments
- Ideal for 24/7 mission-critical operations
Package Contents
- ATEN CL1308 LCD KVM Switch
- AC Power Cord
- Rack Mount Kit
- Quick Start Guide
- User Documentation
